Sensory substitution means replacement of one sensory input (vision, hearing, touch, taste or smell) by another, while preserving some of the key functions of the original sense. In particular, research in this area aims at providing some equivalent of vision via hearing or touch, or some equivalent of hearing via vision or touch. Blindness and deafness are generally considered to be among the sensory disabilities that have the greatest impact on everyday life, and the quest for good sensory substitution devices or prostheses for blindness and/or deafness therefore presents a great challenge. In case of partial blindness and/or deafness, sensory substitution may also augment rather than fully replace.

Let's see... about sensory substitution
	BrainPort vision device tongue display	AuxDeco FSRS forehead display	The vOICe auditory display
Cost estimate	~$10,000	~$15,000	< $500 *
Pixels (electrodes)	~400	512	> 10,000
Shades of gray	2-4 ?	2-4 ?	> 16
Availability	several countries	Japan	global
* cost indication for a setup based on a Windows netbook PC with camera glasses
YouTube video clips of training during SBIR phase I evaluation study on The vOICe by MetaModal LLC

In the remainder of this page, we will discuss options for vision substitution (also called visual substitution or sight substitution): sensory substitution targetting (total) blindness. Deafness lies outside the scope of this site, although much progress has been made in recent years with the development of cochlear implants. The cochlear implant is a prosthetic sensory bypass rather than a sensory substitution device, but the fact that it maps acoustical inputs (one physical modality) directly onto neural stimuli (another physical modality) raises several issues and problems that are similar to those in sensory substitution devices mapping one sensory modality to another. Sensory substitution approaches may also play a role in other sensory prosthetics, for instance for sensory augmentation or  cognitive augmentation through neuroelectronics. On the website of  Dr. Timothy Hain (dizziness-and-hearing.com) a number of literature references on the use of auditory and other sensory feedback for treating bilateral vestibular loss are given.

Vision Substitution

1. Reading and writing

   Louis Braille (1809-1852) in the 19th century developed the well-known raised dot code now named after him. This tactile representation was later supplemented by blindness aids like the mechanical Braille printer and typewriter (Brailler), again followed by more versatile electronic implementations.

   In the early 1960s, John Linvill and James Bliss developed the  Optacon, involving a tactile 6 × 24 matrix of vibrating pins comprising an area of 12.7 × 29.2 mm and with active pins vibrating at about 230 Hz. The Optacon directly maps the brightness input from a camera to a corresponding vibrotactile pattern representing printed (non-Braille) characters in the field of view of the camera. Production of the Optacon by TeleSensory was discontinued end 1996. A direct auditory representation of print was provided by the camera-based 10-tone Stereotoner, which sounded 1 column of 10 pixels at any given moment while the user had to manually scan the print by moving the camera over it.

   In another attempt to circumvent the difficulty of reading Braille, the Kurzweil reading machine (KRM) was developed around 1975 by Raymond Kurzweil. This device is an early dedicated text-to-speech engine, of which newer versions have been made. As with the Optacon, increased competition may come from Soundblaster-type speech synthesizers that are now commonly and cheaply available in multimedia PC's, combined with optical character recognition (OCR) software and a camera for acquiring (printed) textual material that is not already electronically available in the form of ASCII characters.

   Screen magnifiers (CCTV's), including contrast enhancement, were developed as visual aids for the partially sighted.

2. Obstacle detection and avoidance

   Obstacle detectors are intended to improve orientation and mobility by giving spatial information about the immediate neighourhood relevant to navigation while walking. Electronic devices for that purpose are therefore also termed electronic travel aids (ETAs) or blind mobility aids.

   The long cane is a very simple but effective mechanical device for probing the environment for obstacles through touch, but also to some degree through acoustical reflections resulting from tapping. Its range for providing touch feedback is only a few feet, and it does not normally detect overhanging obstacles. The guide dog has helped to alleviate some of the limitations of the long cane for (some) blind travellers, but w.r.t. general orientation and navigation it still provides little information.

   Peter Meijer (left) wearing Tony Heyes' (right) Sonic Pathfinder. May 31, 1997.

   Particularly the early ETA's tried to extend the small range and angular coverage of the long cane either acoustically (ultrasonically) or optically (laser light). A German laser cane (German: Laser-Langstock) is under development at  VISTAC GmbH. The Mowat sensor and Nottingham obstacle detector (NOD) are both hand-held ultrasonic torches, developed around 1980, that map ultrasonic reflections into vibrotactile or auditory signals, respectively. The Mowat and NOD devices are no longer in production. Leslie Kay, Tony Heyes and Allan Dodds played a central role in the development of sonar-based aids for the blind. Kay developed an environmental imaging sensor called the Sonicguide that provides more spatial information than the early obstacle detectors.

    Tony Heyes has improved upon the Nottingham obstacle detector (NOD), and his device is known as the Sonic Pathfinder (1984). This is a head-mounted pulse-echo sonar system comprising three receivers and two transmitters, controlled by a microcomputer.

   Tony Heyes (left) explaining the Pathfinder to Hester. May 31, 1997.

   It does not give information about surface texture, and normally the auditory display indicates only the nearest object, which is why it should be classified as an obstacle detector rather than as an imaging device. Heyes' approach is rather different from Kay's in that the Sonic Pathfinder deliberatily supplies only the minimum but most relevant information for travel needed by the user, whereas Kay strives for more information-rich sonar-based displays. Heyes argues, for instance, that if some object moves away from the user, the user does not need to know this in terms of safe and efficient travel, and there may also be less confusion while minimizing interference with hearing normal environmental sounds (e.g., traffic). The Sonic Pathfinder uses brief tones on a musical scale to denote distance, with pitch descending when approaching an object. Perception of objects on the left and on the right is further supported by tones for the corresponding ear. Two additional, off-center, sonar beams are used to detect objects on the left or right. The Sonic Pathfinder is used in conjunction with the long cane.

   Other sonar devices for the blind include the  Miniguide,  UltraCane, BAT 'K' Sonar-Cane (ksonar.com no longer online) and an optional sonar extension for The vOICe.

There are several distinct sensory substitution approaches heading towards medium resolution environmental imaging:

• Cortical or retinal electrode matrix display

  In the experimental cortical implant approach one uses an array of electrodes placed in direct contact with the visual cortex. This is also called a neuroprosthesis or brain implant. Pioneered by Giles Brindley in the 1960s, and William Dobelle (1941-2004) et al. in the early 1970s. Research into cortical implants is also done by Richard Normann, Mohamad Sawan and others. The cortical implant is an invasive approach, requiring major surgery. Maximum resolution of the implants is so far on the order of 10 × 10 pixels. Individual pixels are perceived as phosphenes (sensations of light, flashes). See also the brain implant page for more information and discussion. A related research topic is the development of the retinal implant for artificial sight. The retinal implant approach may in the future help in treating blindness resulting from malfunctioning of the retina. It will not help with blindness resulting from optic nerve damage (e.g., due to diabetes or glaucoma) or brain damage.

• Electrocutaneous or vibrotactile display

  Tongue display

  Forehead Retina System

  Paul Bach-y-Rita (1934-2006) et al. have developed the Tactile Vision Substitution System (TVSS) around 1970. The TVSS tactile display maps images from a video camera to a vibrotactile belt worn on the abdomen, and offers black-and-white images at a resolution of 20 × 20 pixels in the tactile array. Later (1985) a haptic system based on the Optacon was developed, offering a higher resolution by using a scanning technique, where the Optacon ``window'' is moved across a much larger image. More recently,  Kurt Kaczmarek and Paul Bach-y-Rita developed an electro-tactile tongue display unit (TDU) with an array of 144 stainless steel electrodes, organized as a 12 × 12 pixel matrix. The commercial version is now known as the "BrainPort" vision device from  Wicab, having a 20 × 20 electrode matrix and a price indication of $10,000 (BrainPort V100). Contrary to The vOICe (see below for a description on The vOICe approach) one cannot eat or talk while using the tongue display. A newer headband-style  BrainPort Vision Pro ( BrainPort V200) is now available. Although the default frame rate may be somewhat higher than with The vOICe, one likely needs "tongue saccades" to interpret complex images with multiple shapes, thereby effectively adding a significant perceptual latency to the technical latency. Running reportedly interferes with the ability to perceive with the tongue display. Recent work proceeded towards a 611-electrode display, but the perceptual gain from this technical resolution increase will likely be limited. The same is expected for the  High Density Tongue Display (HDTD) module with reportedly a 100 × 100 electrode array. It is unclear if continuous and long-term use of electrical stimulation of the tongue is safe, but the BrainPort V100 nevertheless received  FDA approval in 2015. Wicab expects to be acquired at some point by a medical technology company. For more information, see the  Tactile Communication and Neurorehabilitation Laboratory (TCNL), the  How BrainPort Works article on howstuffworks, the  Tongue Vision article in IEEE Spectrum (Sandra Upson, January 2007). A general question about sensory substitution remains to what extent it can give rise to visual sensations. In a KDKA Pittsburgh news coverage in 2009, blind user Michael Jernigan reported what using the BrainPort was like, in saying "You don't really see; I think that one of the common misconceptions with the BrainPort is that it gives the blind sight". The tongue display is also marketed for treating severe balance disorders related to vestibular dysfunction. However, in Spring 2010, Wicab stopped manufacturing of the BrainPort Balance Device as a result of inconclusive FDA clinical trials. Another camera-based tactile display is the AuxDeco Forehead Sensory Recognition System (FSRS, formerly Forehead Retina System, FRS), developed by Yonezo Kanno, CEO, and Hiroyuki Kajimoto ( EyePlusPlus, Inc.) in cooperation with Tachi Laboratory and the University of Tokyo in Japan. This visual substitution system uses 512 electrodes (32 × 16 matrix) operating with very short 300 volt pulses ( SIGGRAPH 2006 Emerging Technologies), aiming to map color channels through separate stimulation of four mechanoreceptor types in the skin: Meissner corpuscles, Merkel cells, Ruffini endings and Pacinian corpuscles.  FingerSight and  iFeelPixel also use a camera as the input device for giving tactile feedback.

• Auditory display

  Whereas the former two approaches were (implicitly) using visual input, research on auditory displays currently considers two options for environmental input to create a visual prosthesis (through an Auditory Vision Substitution System, or AVSS):

  1. Sonar input (ultrasonic)

      Leslie Kay (1922-2020) has done much research on sonar devices, leading to the ``sonic glasses,'' or Sonicguide, around 1974. More recently, he has improved the angular resolution of his Binaural Sensory Aid (BSA) system using a third narrow beam transmitter for creating an additional monaural signal. This newer system was first called the Trisensor, but is now known as the KASPA system (Kay's Advanced Spatial Perception Aid). KASPA represents object distance by pitch, but also represents surface texture through timbre. Use is made of echo location through frequency-modulated (FM) signals. The improved, but still modest, resolution probably positions Kay's work somewhere between obstacle detection and environmental imaging. The best angular resolution is about one degree in the horizontal plane (azimuth detection) for the central beam, which is quite good, but vertical resolution (elevation) is poor - making the ``view'' somewhat similar to constrained vision with binocular viewing through a narrow horizontal slit.

     Note: It remains difficult to settle on a good measure for equivalent image resolution as offered by sonar approaches, because sonar is not based on mapping an image matrix to another sensory modality, but on the implicit preservation of some degree of detailed environmental information in complex ultrasonic interference and acoustic delay patterns, thus supporting spatial processing. Nevertheless, Kay's work does show some features (resolution, texture, parallax) that support its classification as an imaging device, or vision substitute.

  2. Camera input (visual)

     Peter Meijer developed a device that maps grey-scale images from a video camera into corresponding soundscapes. A first implementation of this device, nicknamed The vOICe, was made using low-cost hardware (1991). It attained real-time performance through a pipelined design, and offered a resolution of 64 × 64 pixels and 16 shades of grey. For a 60 degree field of view (any value is possible through the choice of camera lens), this would imply a one degree resolution for both azimuth and elevation. The unusually high resolution - for an auditory display - was made possible through a scanning technique that enables a trade-off between resolution and synchrony with environmental changes. Later on, Meijer made world-wide access to a software demonstration of its operating principles possible through a multimodal Java applet (1996) running from an Internet page. In addition, The vOICe for Windows (1998 and later) now fully integrates camera input, video sonification and headphones output for use with closed-loop adaptive mobile systems, while for mobile camera phones there are The vOICe MIDlet (2003 and later, now obsolete) and The vOICe for Android (2008 and later). Television coverage in Tech Live (TechTV) and Nano - The world of tomorrow (3Sat/WDR, in German), and radio coverage in  Quirks & Quarks (CBC Radio One).

     Pending psychophysical and neuroscientific experiments on the role of mental imagery and visualization in auditory synthetic vision, images have been reconstructed from The vOICe sounds through computer analyses in order to prove the preservation of a significant amount of image information in the sounds. The vOICe mapping thus creates a near-isomorphism between vision and hearing for a limited resolution and frame rate. An example reconstruction is shown below:

     The vOICe in IEEE Spectrum

     Eduverse 2008 presentation by Peter Meijer

     So far, the psychophysical or psychological research community has not yet found conclusive answers w.r.t. the potential of this approach for the blind, and the relevant limitations in human auditory perception and learning abilities for comprehension and development of visual qualia (sensations) therefore remain largely unknown or anecdotal, although the training effort is expected to be significant while involving perceptual recalibration for accurate sensorimotor feedback. One of the key research questions is to what extent the use of a sensory substitution system cannot only provide synthetic vision in a functional sense for extended situational awareness through active sensing, but also lead to visual sensations through forms of induced artificial synesthesia. Also see the auditory model page for computer simulations of human auditory processing of The vOICe sounds, and the related projects page for other projects in which image-to-sound mappings similar to or related to The vOICe mapping are employed.

  Precursors of general sensory substitution for 2D vision using visual input include the originally 0D (single-pixel)  Elektroftalm and 1D (column, text-reading)  Optophone.

Literature and conference presentations:

The New York Times on sensory substitution:

 ``New Tools to Help Patients Reclaim Damaged Senses,'' by Sandra Blakeslee for The New York Times, November 23, 2004.

``In another approach, Dr. Peter Meijer, a Dutch scientist working independently, has developed a system for blind people to see with their ears. A small device converts signals from a video camera into sound patterns delivered by stereo headset to the ears. Changes in frequency connote up or down. Changes in pixel brightness are sensed as louder or softer sounds.''

The New Scientist on sensory substitution:

 ``Senses special: The feeling of colour (subscription required),'' by Helen Phillips for the New Scientist, January 29, 2005, pp. 40-43.

``In preliminary tests with a similar device designed by engineer Peter Meijer from Eindhoven in the Netherlands, the signals took a little getting used to. But after a couple of hours of feedback either from touching or being told what they were viewing, people were able to recognise objects by their sound. They could tell plants from statues and crosses from circles. But they weren't fooled into thinking they were seeing. O'Regan's prediction is that the more they can make the sound information follow the rules of visual images, the more like seeing it will feel.''

The New York Times on The vOICe:

 ``Seeing With Your Ears,'' by Alison Motluk for The New York Times, December 11, 2005.

On The vOICe approach (camera input auditory display research):

Meijer, P.B.L., ``An Experimental System for Auditory Image Representations,'' IEEE Transactions on Biomedical Engineering, Vol. 39, No. 2, pp. 112-121, Feb 1992. Reprinted in the 1993 IMIA Yearbook of Medical Informatics, pp. 291-300.

Meijer, P.B.L., ``Cross-Modal Sensory Streams,'' invited presentation and demonstration at SIGGRAPH 98 in Orlando, Florida, USA, July 19-24, 1998. Conference Abstracts and Applications, ACM SIGGRAPH 98, 1998, p. 184.

Meijer, P.B.L., ``Seeing with Sound for the Blind: Is it Vision?,'' invited presentation at the Tucson 2002 conference on Consciousness in Tucson, Arizona, USA, Monday April 8, 2002.

Fletcher, P.D., ``Seeing with Sound: A Journey into Sight,'' invited presentation at the Tucson 2002 conference on Consciousness in Tucson, Arizona, USA, Monday April 8, 2002.

Amedi, A., Camprodon, J., Merabet, L., Meijer, P. and Pascual-Leone, A., ``Towards closing the gap between visual neuroprostheses and sight restoration: Insights from studying vision, cross-modal plasticity and sensory substitution,'' [Abstract]. Journal of Vision, Vol. 6, No. 13, 12a, 2006. Abstract available  online.

Amedi, A. Stern, W., Camprodon, J. A., Bermpohl, F. Merabet, L., Rotman, S. Hemond, C., Meijer, P. and Pascual-Leone, A. ``Shape conveyed by visual-to-auditory sensory substitution activates the lateral occipital complex,'' Nature Neuroscience, Vol. 10, No. 6, pp. 687 - 689, June 2007.

Proulx, M. J., Stoerig, P., Ludowig, E. and I. Knoll,  ``Seeing 'Where' through the Ears: Effects of Learning-by-Doing and Long-Term Sensory Deprivation on Localization Based on Image-to-Sound Substitution,'' PLoS ONE, Vol. 3, No. 3, March 2008, e1840.

Kim, J.-K. and Zatorre, R. J., ``Generalized learning of visual-to-auditory substitution in sighted individuals,'' Brain Research, Vol. 242, pp. 263-275, 2008. Available  online (PDF file).

Merabet, L. B., Battelli, L., Obretenova, S., Maguire, S., Meijer P. and Pascual-Leone A., ``Functional recruitment of visual cortex for sound encoded object identification in the blind,'' Neuroreport, Vol. 20, No. 2, pp. 132-138, January 2009.

Striem-Amit, E.,  ``Neuroplasticity in the blind and sensory substitution for vision,'' PhD thesis, 2013 (PDF file).

For other useful literature check out recent publications about sensory substitution. In relation to audio biofeedback (ABF), balance problems and visual impairment, see

Dozza, M., Chiari, L., Chan, B., Rocchi, L., Horak, F. B. and Cappello, A., ``Influence of a Portable Audio-Biofeedback Device on Structural Properties of Postural Sway,'' Journal of Neuroengineering and Rehabilitation, Vol. 2, No. 13, May 2005. Available  online (PDF file).

Growing military interest in sensory substitution is implied in the 2008 National Research Council (NRC) report for the US Defense Intelligence Agency, titled  "Emerging Cognitive Neuroscience and Related Technologies", which refers to both The vOICe (Motluk, 2005) and tactile displays (Bach-y-Rita and others). This report was authored by the "Committee on Military and Intelligence Methodology for Emergent Neurophysiological and Cognitive/Neural Research in the Next Two Decades".
